ASUS RS100-E10-PI2/250W - 90SF00G1-M01310
Powered by the Intel® Xeon® E platform 95W CPU and up to 128GB memory support (4 DIMMs) Flexible storage expandability with up to 5 storage devices Two M.2 slots accommodate 22110-size SSDs for faster boot speed
TIER III minősítésű adatközpontunkban most fél évre ingyenesen bérelhet tárhelyet.
De nem csak ez - kérjen tőlünk egyedi szerverkonfigurációt! Mi megtervezzük, összeállítjuk, szakértő módon telepítjük és kiterjesztett vagy NBD garanciát biztosítunk.
| termékkód | 202.160093 |
|---|---|
| Part number | 90SF00G1-M01310 |
| EAN | 4711081011828 |
| Gyártó | ASUS |
| Elérhetőség | A beszállítónál készleten |
| Garancia (hónap) | 36 hónap |
| Súly | 7.5 kg |
| Az ár tartalmazza az összes törvényes díjat | |
Részletes információk
Delivers a workload optimized solution
RS100-E10-PI2 supports the latest Intel® Xeon® E processors, which are 2x faster than the previous generation and operate at a maximum of 95W for leading performance. It supports four memory slots that fit up to 128GB of DDR4 2666 for memory-intensive computing.
RS100-E10-PI2 supports the latest Intel® Xeon® E processors, which are 2x faster than the previous generation and operate at a maximum of 95W for leading performance. It supports four memory slots that fit up to 128GB of DDR4 2666 for memory-intensive computing.
Supports
Latest Intel Xeon E
Up to
128 GB
Support
PCIe Gen3
Comprehensive IT infrastructure management
RS100-E10-PI2 features an optional embedded iKVM module and is bundled with ASUS Control Center to provide comprehensive out-of-band and in-band management features for small and mid-size businesses. The optional ASMB9-iKVM module supports remote BIOS updates, fan control, standalone KVMs, video recording, and BSOD capture, providing around-the-clock remote monitoring and diagnostics — even if the operating system is down or offline — through a user-friendly, web-based graphical interface that works with all major browsers. ASUS Control Center (ACC) is a centralized and integrated IT management platform for monitoring and controlling ASUS commercial products, including servers, workstations and digital signage. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.
RS100-E10-PI2 features an optional embedded iKVM module and is bundled with ASUS Control Center to provide comprehensive out-of-band and in-band management features for small and mid-size businesses. The optional ASMB9-iKVM module supports remote BIOS updates, fan control, standalone KVMs, video recording, and BSOD capture, providing around-the-clock remote monitoring and diagnostics — even if the operating system is down or offline — through a user-friendly, web-based graphical interface that works with all major browsers. ASUS Control Center (ACC) is a centralized and integrated IT management platform for monitoring and controlling ASUS commercial products, including servers, workstations and digital signage. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.
-
- Processor
CPU Intel® Xeon® processor E-2100 family
Intel® Xeon® processor E-2200 family
The 8th/9th generation Intel® Core™ i3/Pentium®/Celeron® ProcessorSocket 1 x Socket LGA1151 Core Logic Intel® C242 Chipset - System memory
Memory maximum Capacity Maximum up to 128GB UDIMM Memory Slots 4 (2-channel) Memory Type DDR4 2666/2400 UDIMM non ECC and with ECC - Expansion slots
PCIe Total PCI/PCI-X/PCIe/PIKE Slots: 1
1 x PCIe x16 (x16 Gen3 Link)- Storage
Drive Bays with ODD, up to 2 x3.5" disk bay or option 1x3.5"+2x2.5" disk bay support
without ODD, up to 2 x3.5" disk bay or option 1x3.5"+4x2.5" disk bay supportM.2 2 x M.2 connector(2242/2260/2280/22110) both SATA & PCIe mode *2 SATA Controller Intel® C242 Chipset
2 x Internal 3.5” HDD
2 x M.2 connector(2242/2260/2280/22110) both SATA & PCIe mode *2
Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows)
(Support Software RAID 0, 1 )Auxiliary Storage FDD/CD/DVD 1 x Slim-type Optical Drive Bay
Options: No Device / DVD-RW- Graphic
Graphic Aspeed AST2500 with 32MB VRAM - Networking
Networking 4 x Intel® I210AT + 1 x Mgmt LAN
-
- I/O Ports
Front I/O Ports 2 x USB 3.0 ports
1 x VGA portRear I/O Ports 1 x External Serial Port
4 x RJ-45 ports
2 x USB 3.1 ports
2 x USB 3.0 ports
1 x VGA port
1 x RJ-45 ports (One for ASMB9-iKVM)(Optional)- Switch/LED
Rear Switch/LED 1 x Q-Code/Port 80 LED
1 x Power switchFront Switch/LED 1 x Power switch/LED
1 x Location switch/LED
1 x Reset switch
1 x HDD Access LED
1 x Message LED
LAN 1-4 LED- Management Solution
Management Solution ASUS Control Center Enterprise (Optional)
Optional ASMB9-iKVM for KVM-over-IPRegulatory Compliance BSMI, CE, RCM, FCC(Class B) - Dimensions
Form Factor 1U Height 44mm Width 430mm Depth 380mm Weight 11.72 Kg - Power supply
Power Single 250W 80 PLUS Gold Power Supply
Rating: 100-240Vac,4A ,50-60Hz, Class I
Single 350W 80 PLUS Gold Power Supply
Rating: 100-240Vac,6A-3A ,50-60Hz, Class I
Paraméterek
| U méret | 1 |
|---|---|
| Mélység mm | 430 |
| A cpu gyártója | Intel |
| Socket | 1151 (H4) |
| Merevlemezek száma | 2 |
| 2.5"-os meghajtóhelyek száma | 2 |
| 3.5"-os meghajtóhelyek száma | 2 |
| NVME slotok száma | 2 |
| PCIe teljes száma | 1 |
| OCP/AIOM | 0 |
| Teljesítmény (W) | 250 |
| Hatékonyság tanúsítás | Bronze |
