Ampere® Altra® Max Processor
Ampere’s Altra® family of processors are designed to deliver on predictable performance, high scalability and power efficiency. Ampere’s leadership on all these metrics deliver exceptional results and lower the TCO for Cloud Service Providers.
Servers
GIGABYTE Builds
Rackmounts
Max I/O Systems
Network Server
GIGABYTE R182-P91 (rev. 100) - 6NR182P91DR-00
GIGABYTE R182-P91 (rev. 100) - 6NR182P91DR-00
Ampere® Altra® Max Processors Dual processor, 7nm technology 8-Channel RDIMM/LRDIMM DDR4, 32 x DIMMs Dual ROM Architecture 2 x 1Gb/s LAN ports (Intel® I350-AM2) 1 x Dedicated management port 6 x 2.5" Gen4 NVMe/SATA hot-swappable bays 6 x 2.5" Gen4 NVMe hot-swappable bays 1 x M.2 slot with PCIe Gen4 x4 interface 2 x FHHL PCIe Gen4 x16 slots 2 x OCP 3.0 Gen4 x16 slots 1+1 1300W 80 PLUS Platinum redundant power supplies
TIER III minősítésű adatközpontunkban most fél évre ingyenesen bérelhet tárhelyet.
De nem csak ez - kérjen tőlünk egyedi szerverkonfigurációt! Mi megtervezzük, összeállítjuk, szakértő módon telepítjük és kiterjesztett vagy NBD garanciát biztosítunk.
| termékkód | 202.171405 |
|---|---|
| Part number | 6NR182P91DR-00-1 |
| Gyártó | GIGABYTE |
| Elérhetőség | A beszállítónál készleten |
| Garancia (hónap) | 24 hónap |
| Súly | 20 kg |
| Az ár tartalmazza az összes törvényes díjat | |
Részletes információk
Power Efficiency
GIGABYTE servers are enabled with Automatic Fan Speed Control to achieve the best cooling and power efficiency. Individual fan speeds will be automatically adjusted according to temperature sensors strategically placed in the servers.
High Availability
To prevent server downtime and data loss as a result of loss of AC power, GIGABYTE implements SmaRT in all our server platforms. When such an event occurs, the system will throttle while maintaining availability and reducing power load. Capacitors within the power supply can supply power for 10-20ms, which is enough time to transition to a backup power source for continued operation.
Hardware Security
For hardware-based authentication, the passwords, encryption keys, and digital certificates are stored in a TPM module to prevent unwanted users from gaining access to your data. GIGABYTE TPM modules come in either a Serial Peripheral Interface or Low Pin Count bus.
Performance Boost
Up to 80 /128 cores and 128 PCIe lanes demand data to be processed quickly and more jobs at the same time.
Architecture Efficiency
Designed for Cloud and Edge (cloud ecosystem native platform) and provides a high number of computing cores, faster throughput, and low power consumption.
Aggregate Powerhouse
Provides a management tool for cloud and edge to simplify management and improve efficiency.
Superhighway of Data
Utilizing the latest in PCIe 4.0 and 128 PCIe lanes allows faster throughput in GPUs, storage and networking.
Green Savings
Best in class performance/watt, Ampere® Altra® continues to increase value while driving down TCO.
-
- Motherboard
Part number MP92-FS0 - Processor
CPU Ampere® Altra® Max Processor
Dual processor, 7nm technologySocket 2 x LGA 4926 TDP Up to 128-core per processor, TDP 250W - System memory
Memory maximum Capacity RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
Up to 4TB of memory capacity supported per processorMemory Slots 32 x DIMM slots Memory Type DDR4 memory supported only
8-Channel memory architecture
Memory speed: Up to 3200 MHz- LAN
Total Rear side:
2 x 1Gb/s LAN ports (1 x Intel® I350-AM2)
NCSI function supported
1 x 10/100/1000 Mbps management LAN- Video
Video Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM- Storage
Drive Bays Front side:
6 x 2.5" Gen4 NVMe/SATA hot-swappable bays
- (NVMe from CPU_0, SATA from CPU_1)
6 x 2.5" Gen4 NVMe hot-swappable bays, from CPU_1Backplane Board PCIe Gen4 x4 or SATA 6Gb/s - Expansion slots
PCIe Riser Card CRS101J:
- 1 x PCIe x16 (Gen4 x16) FHHL slot
Riser Card CRS101K:
- 1 x PCIe x16 (Gen4 x16) FHHL slot
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth, from CPU_0
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth, from CPU_1
-
- Input/output
Front I/O 1 x USB 3.2 Gen1
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x SSD activity LED
1 x System status LEDInternal I/O 1 x M.2 slot
1 x TPM header
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumperRear I/O 2 x USB 3.2 Gen1
1 x Mini-DP
2 x RJ45
1 x MLAN- TPM
TPM 1 x TPM header with SPI interface - Power supply
Certification Platinum Power 1+1 1300W 80 PLUS Platinum redundant power supplies (-100) QTY 2 - Dimensions
Form Factor 1U Height 43.5 mm Width 438 mm Depth 815 mm - Managment
Software Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings- System Fans
System Fans 8 x 40x40x56mm (29,700rpm)
Paraméterek
| U méret | 1 |
|---|---|
| Mélység mm | 815 |
| A cpu gyártója | Ampere |
| Socket | 4926 |
| Merevlemezek száma | 13 |
| 2.5"-os meghajtóhelyek száma | 12 |
| 3.5"-os meghajtóhelyek száma | 0 |
| NVME slotok száma | 12 |
| PCIe teljes száma | 2 |
| OCP/AIOM | 1 |
| Teljesítmény (W) | 1300 |
| Hatékonyság tanúsítás | Platinum |
