Part Number |
Qty |
Description |
| Air Shroud |
MCP-310-29001-0N |
1 |
SC825/826/216/213 Intel DP X9,X8 air shroud 13.68x13/12x13 |
| HD Backplane |
BPN-SAS-825TQ |
1 |
8-port 2U TQ (W/ AMI 9072) backplane, support up to 8x 3.5-inch SAS/SATA HDD |
| Cable(S) |
CBL-0071L |
1 |
CBL,FRONT CNTL,16 TO 16 PIN,RA,RND TUBE,75CM,28AWG |
| Cable(S) |
CBL-0157L |
2 |
CBL,SGPIO,2X4F TO 2X4F,P2.54,RIBBON IN RND TUBE,40CM,28AWG |
| Cable(S) |
CBL-0160L |
1 |
NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt) |
| Cable(S) |
CBL-0180L-01 |
1 |
SATA,INT,ROUND,SET OF 4,ST-RA 70/59/48/38CM,26AWG |
| CD-ROM & Accessory |
MCP-290-00007-01 |
1 |
Black DVD dummy cover for SC825, 836 |
| Fan(s) |
FAN-0126L4 |
3 |
80x80x38 mm 7K RPM Chassis Middle Fan w/ Housing |
| Front Panel |
FPB-FP836-D |
1 |
Front control board Dual color LED(FP836-D)forSC823M,825,825M,828,829,835,836 |
| Drive Tray(s) |
MCP-220-00023-01 |
1 |
Black USB dummy tray support 1x 2.5" slim HDD for SC825, 836 |
| Drive Tray(s) |
MCP-220-00075-0B |
8 |
Black gen 5.5 hot-swap 3.5"; HDD tray |
| Drive Tray(s) |
MCP-220-82502-0B |
2 |
Black fixed 3.5" HDD tray or FDD dummy tray |
| Power Supply & Accessory |
CSE-PT0130L |
1 |
SC745 Power Supply Dummy Cover (76mm wide, 700W/800W/900W) |
| Power Supply & Accessory |
PWS-605P-1H |
1 |
1U 600W Multi Output Power Supply PMbus |
| Mounting Rail(s) |
MCP-290-00053-0N |
1 |
Rail set, quick/quick, default for 2,3U 17.2";W |
| Rear Window |
MCP-240-00102-0N |
1 |
2U WIO rear window for SC825, SC826, SC213, SC216 |
|
|
