QSAN XCubeNXT XN8126S_8C - 90-N8126S10-EU
XN8126S_8C, NXT, Single CTRL, Intel 8core Xeon, DDR4 16G, 10GbE SFP+*4, 2U26, GBIC*2, Rail kit
| termékkód | 244.170711 |
|---|---|
| Part number | 90-N8126S10-EU |
| EAN | 4710474329960 |
| Gyártó | QSAN |
| Elérhetőség | A beszállítónál készleten |
| Garancia (hónap) | 36 hónap |
| Súly | 18.6 kg |
| Az ár tartalmazza az összes törvényes díjat | |
Részletes információk
Easy File Access with Quick Connection
QSAN XN8000 is a powerful unified storage system, composed of the system hardware and the QSM operating system, designed for both enterprise and SMB users. The system hardware is a modular design and FRU (field replacement unit) optimized, features the Intel enterprise level Xeon CPU and up to 128GB of DDR4 ECC RAM. All the hardware modules are inside the rackmount chassis including: system controllers, front panel, rear panel, redundant power supply and fan modules, and expansion slots for optional 10GbE or 1GbE host cards.
High Availability and Enterprise Reliability
The XCubeNXT provides ultra-high scalability. Companies may make cost-effective planning in the initial stage of expansion. When the demand gets larger, both hardware and capacity could be scaled up. And all this does not need to stop any services.
Intel® Xeon® 8-core Processor
Performance Density
Active-Active Architecture
-
- Processor
CPU Intel® Xeon® 64-bit 8-core - System memory
Memory Module Pre-installed 16 GB DDR4 ECC DIMM (per controller) Total Memory Slots 4 (per controller) Memory Expandable up to 256 GB (per controller) - Storage
Drive Bays 2.5" Slot x 26 Maximum Drive Bays with Expansion Unit 546 Compatible Drive Type 2.5" SAS, NL-SAS, SED HDD
2.5" SATA(*) HDD
2.5" SAS, SATA(*), SED SSDDrive Interface SAS 12 Gb/s, SATA 6 Gb/s(*) Maximum Internal Raw Capacity 798 TB (calculate 30.72 TB SSD) Maximum Raw Capacity with Expansion Units 16,773 TB (calculate 30.72 TB SSD) Hot Swappable Drive Yes - Network
1 GbE RJ45 LAN Port 1 (onboard per controller) 10 GbE SFP+ LAN Port 4 (onboard per controller) / 4 (option) 10 GbE RJ45 LAN Port 2 (option) / 4 (option) 25 GbE SFP28 LAN Port 2 (option) / 4 (option) 16 Gb SFP+ Fibre Channel* 2 (option) / 4 (option) 32 Gb SFP28 Fibre Channel* 2 (option)
-
- Expansion slots
PCIe (Gen 3x8 Slot) x 2 12 Gb/s SAS Wide Port 2 (onboard per controller) USB Port 1 (front) / 2 (rear) Others Console Port x 1, Service Port (UPS) x 1 - Dimensions
Form Factor 2U Height 88 mm Width 438 mm Depth 491 mm Weight 18.6 kg - Power supply
Certification Platinum Power 850 W x 2 (80 PLUS Platinum) Power Consumption 429 W
Paraméterek
| U méret | 2 |
|---|---|
| Mélység mm | 491 |
| A cpu gyártója | Intel |
| Socket | Unknown |
| Merevlemezek száma | 26 |
| 2.5"-os meghajtóhelyek száma | 26 |
| 3.5"-os meghajtóhelyek száma | 0 |
| NVME slotok száma | 0 |
| PCIe teljes száma | 2 |
| OCP/AIOM | 0 |
| Teljesítmény (W) | 850 |
| Hatékonyság tanúsítás | Platinum |
